Marine Solar Masthead Light
KSS307 is a multi-purpose vessel navigation light powered by solar energy and designed to comply with the COLREGS(1972) and UL 1104 standards.
Share this:
The light may become one of the following four lamps.
|
Masthead Light
|
Deck Light
|
Barge Light
|
Morse Signal Light
|
|
225° White Output
|
360° Down White
|
112.5° ;135°
|
Morse Code
|
If you want the light to have more than one function,the four functions of light can be combined and selected by an IRC.
|
Features & Benefits
|
|
|
◆
|
Optional colors: Red ,White
|
|
◆
|
Can switch the warning and lighting function.
|
|
◆
|
It takes only a few minutes to install.
|
|
◆
|
Automatically turns on at dusk and off at dawn
|
|
◆
|
Will charge under nearly all weather conditions and up to 100 hours of operating capacity from a full charge.
|
|
◆
|
Completely self-contained and watertight.
|
|
◆
|
Polycarbonate lens is virtually indestructible.
|
|
◆
|
Waterproof IP67
|
|
◆
|
Manufactured to ISO9001:2008 Quality Assurance standards
|
|
Typical Applications
|
|
|
◆
|
Fishing Boat
|
|
◆
|
Tug Boat
|
|
◆
|
Tow Boat
|
|
◆
|
Barge
|
|
◆
|
Dredger
|
|
SPECIFICATIONS
|
||||
|
MODEL
|
KSS307
|
KSS305/3.5NM
|
KSS307/MC
|
KSS307/DL
|
|
Masthead Light
|
Barge Light
|
Morse Signal Light
|
Deck Light
|
|
|
Light Output
|
225°
|
112.5°、135°
|
360°(Horizontal)
|
360°(Down)
|
|
Visibility
|
3NM
|
3.5NM
|
6NM
|
1NM
|
|
Minimum Autonomy
|
100hrs
|
100hrs
|
140hrs
|
30hrs
|
|
LED
|
24Pcs
|
48Pcs
|
||
|
Effective Intensity
|
White:STEADY ON112.0cd ; FLASHING180.0cd
|
|||
|
Red:STEADY ON80.0cd ; FLASHING150.0cd
|
||||
|
Operation
|
||||
|
Latitude Range
|
55°S to 55°N
|
|||
|
On/Off Level
|
60/100 Lux
|
|||
|
Lifespan of LEDS
|
up to 100,000 Hours
|
|||
|
Solar panels
|
||||
|
Type
|
mono-crystalline
|
|||
|
Maximum Power
|
7Wp
|
|||
|
Efficiency
|
16%
|
|||
|
Battery
|
||||
|
Type
|
Lithium , replaceable
|
|||
|
Capacity
|
10.5Ah/7.2V
|
|||
|
Construction
|
||||
|
Lens Material
|
Polycarbonate
|
|||
|
Colored Lens Option
|
Red or white
|
|||
|
Mounting Option
|
4 bolts or Magnetic base
|
|||
|
Weight
|
2.4kg
|
|||
|
Environment
|
||||
|
Temperature Range
|
-40℃ to +80℃
|
|||
|
Waterproof
|
IP67
|
|||
More details of product, welcome to contact kevin@kingseamarine.com.
