Marine Automatic Antenna Tuner
Automatic Antenna Tuner Suitable for various vessels
The versatile KAT-130 can be used with a variety of vessels, even smaller boats that cannot use a long antenna element Automatic tuning
No manual tuning is needed. Just push the [TUNE] switch on HF marine transceiver; the KAT-130 adjusts the antenna and the Transceiver to the minimum SWR in any frequency on an HF marine band. …
Share this:
- Dimensions: 230(W) x 340(H) x 80 (D) mm; 9.1(W) x 13.4(H) x 3.1(D) in (projections not included)
- Weight: 2.5 kg; 5.5lb
- Usable Temperature Range: -30 o C ~ +60 o C
- Rated Voltage: 13.6 V DC +/-15% (negative ground) (supplied from an HF marine transceiver)
- Current Drain (at 13.6 V DC): 2 A
-
Frequency Coverage: 1.6~30 MHz
Lowest Frequency in use
Length of antenna
1.6MHz
12 meters or longer
4MHz
3 meters or longer
8MHz
2 meters or longer
- Input Impedance: 50 ohms (unbalanced)
- Max. Input Power: 150 W (PEP)
- Input Power During Tuning: 10 W
- Auto Tuning Time: 1.5 sec. (returning for a memorized frequency), typically 2~3 sec. (when operating band has been changed)
- Auto Tuning Accuracy: VSWR 2.0:1
- Insertion Loss: 0.5 dB (with a 50 ohms load, after tuning)
More details of product, welcome to contact kevin@kingseamarine.com.
